| Inspection speed |
최대 2m/s (6ft/s) |
| Excitation Frequencies |
Dual frequencies or More |
| Frequency range |
10 Hz ~ 8MHz |
| Inputs(Coil or Hall effect sensor) |
4 independent (8 extended
version) |
| RFEC channel |
8 independent (16 extended
version) |
Probe balancing
|
True menu balancing type |
| Supported probes |
Differential or absolute
bobbin, Hall effect sensor |
| Analog filter |
Low-pass, high-pass |
| Encoders |
2 quadrature encoders
input (option) |
| Inspect method |
moving with speed |
| Eddy type |
Pulse generator |
| Sensing method |
differential or absolute |
| Comparator(비교판정) |
non or be |
| Check Limit |
4 step 4point |
| Power |
AC 220V, DC 12V (option) |
|
|
※ Product specifications are subject to change.
|
 |
