CT Series’ probes have an extremely low mass
(about 3 grams).
→ there is far less wear and tear on the probe
measuring
→ element
→ there is far less chance of damage to sensitive
coatings
• Contact pressure of the probe remains
almost constant whether measurements are taken
from above to down, from the side, or above a
user’s head. |
|
→
It is possible to take precise measurements on
ductile coatings.
•The operation of the CT series is as easy
as the one of a mobile phone.
• With protection class IP52, gauges are
safe from dust and dripping water.
• FN version automatically recognizes the
status of substrate (whether it is ferrous or
non-ferrous) and measures correctly due to its
dual-functioning sensors.
• No calibration necessary unless required
• Three language option: English, French,
German (Other languages on request)
Click to Download
: WT-CT Catalog
|
 |
• CT-F, N, FN
- Equipped with an ergonomically designed
cabled probe,
it is very convenient and useful to take measurements
on small parts and in hard-to-get-at places.
|
• CT-PF, PN, PFN
- Clearly smaller and have no cable. Can be
asily carried in the breast pocket of a shirt
or in the jacket pocket. |
|
|
|
Magnetic Induction Method
Method of measuring all non-ferrous coatings such as
varnish, paint, enamel, chrome, copper, zinc, etc on
steel and iron
Eddy-Current Method
Method of measuring all electrically insulating coatings,
such as varnish, paint, anodizing coatings on non-ferrous
metals and also on stainless steel |
|
|
| |
|
- In the automobile and automobile parts industry
- In paint shops and for electroplaters
- For wet and powder coating operations
- For incoming material inspection during production and for
final inspection procedures
- In development engineering and for expert assessment
- In laboratory and field operations
|
| |
|
 |
| |
|
| CT-FN
or CT-F or CT-N |
With External Probe (standard
version or basic version) |
| CT-PFN
or CT-PF or CT-PN |
With Integrated Probe (standard
version or basic version) |
| CT-FN
or CT-F or CT-N Basic |
Basic Versions without Interface,
Statistics, and Data Memory (external probe) |
| CT-PFN
or CT-PF or CT-PN Basic |
Basic Versions without Interface,
Statistics, and Data Memory (integrated probe) |
| Measuring
Principle |
Magnetic Induction Principle
(F version)
Eddy-Current Principle (N version)
|
| Measuring
Range |
0 ~ 1,500μm (0 ~ 60mils) |
| Tolerance |
±[1μm + 1%] of reading (±[0.04mils+
1%] of reading) |
| Resolution |
0.1μm (0.004mils) or <2‰
of reading |
| Display |
Back-Light (NB), 4-Digit
Alphanumeric, Digit Height for CT model: 10mm, for CT-P
model: 8mm |
| Minimum
Measuring Area |
5mm x 5mm (0.2” x 0.2”) |
| Minimum
Radius of Curvature |
CT model: Convex: 3mm (0.12”),
Concave: 5mm (0.2”)
CT-P model: Convex: 3mm (0.12”), Concave: 30mm (1.2”)
|
| Minimum
Substrate Thickness |
Type F: 0.5mm (20mils)
Type N: 50μm (2mils)
|
| Calibration |
Factory Calibration, Zero
Calibration, Foil Calibration (NB), Offset-Function
(addition or subtraction of a constant value) (NB) |
| Statistics
Program |
Number of Readings, Mean
Value, Standard Deviation, Maximum and Minimum Reading
of Max. 10,000 readings (NB) |
| Memory |
Max. 80 readings, Individual
Reading Review, including Statistical Values (NB) |
| Set
Limits |
Adjustable Selectable with
Accessories Alarm System (NB) |
| Interface |
Infrared IrDA Standard (NB) |
| Power Supply |
2 x 1.5V mignon Alkaline
Batteries (AA) (CT model)
2 x 1.5V micro Batteries (AAA) (CT-P model)
|
| Test Sample
Temperature |
Max. 150℃ (302℉) for Short
Period |
| Ambient
Temperature |
0 ~ 50℃ (32 ~ 122℉) |
| Dimensions
(H x W x D) |
140mm x 62mm x 30mm (5.6”
x 2.5” x 1.2”) (CT model)
99mm x 48mm x 24mm (3.9” x 1.9” x 0.9”) (CT-P model)
|
| Weight |
200g (7oz) (CT model) Including
Batteries
85g (3oz) (CT-P model) Including Batteries
|
| Protection
Class |
IP 52 (Proof against Dust
and Dripping Water) |
| Standards |
DIN, ISO, ASTM, BS |
| Base Instrument
Package |
Gauge with Probe, 2 Calibration
Standards, 2 Batteries, Soft Carrying Pouch, Operating
Manual, Zero Plate(s) |
| Warranty |
A Full One-Year Warranty on
Parts and Labor |
* NB: Not Available for Basic
|
| |
|
• CT-IRA-A Infrared Adapter for
Standard PC and Printer (RS232)
•
CT-CS-N Calibration Standards in Various Thicknesses
|
| |
|
|
|
|
